Description

Calpeda pump B-CM 41/1E:

Calpeda’s C-series monobloc centrifugal pumps are complete with open impeller. Available in either cast iron or bronze, single-phase or three-phase. Centrifugal electric pump made in BRONZE widely used in the nautical sector to transfer and/or deliver fresh water and sea water to all the plants where a large flow rate is needed such as air conditioning, cooling, circulation etc.

Execution

• Close-coupled centrifugal electric pumps with open impeller.
• Backward (vortex) impeller for type C 16/1E.
• C: version with cast iron pump body and fitting.
• B-C: version with bronze pump body and fitting.
• Bronze pumps are supplied fully painted.

Uses

• For liquids moderately charged with impure emulsions.
• For industry and agriculture.

CHARACTERISTICS:

– Bronze connection lantern pump body
– Brass impeller
– 316 stainless steel shaft
– Trim mechanical in hard carbon/ceramic/NBR
– 2900 rpm motor (Continuous duty)
– Class F insulation
– IP 54 protection
– Thermal protection and single-phase capacitor
– IE3 high efficiency three-phase motor from 0.75 kW
– Liquid temperature up to + 90°C
– Ambient temperature up to + 40°C
– Maximum admissible final pressure in the pump body: 6 bars
– Maximum suction height: 8 meters
– Special executions on request

Calpeda pump B-CM 41/1E – FEATURES
